Kit Condutividade Elétrica

DESCRIÇÃO EM PORTUGUÊS BREVEMENTE DISPONÍVEL
Se tiver alguma dúvida neste produto não hesite em contactar-nos

If you are new to electrochemical sensing, knowing what components you need can get confusing. Let us help you.

The Atlas Scientific K1 EZO-Conductivity Kit is perfect measuring water with a conductivity range from 10µs to 100,000µs. That means this kit is perfect for environmental monitoring, hydroponics, and both freshwater and saltwater aquariums.

Kit Includes:

• 1x EZO™ Conductivity Circuit
• 1x Conductivity Probe: 5 µS/cm to 200,000 µS/cm
• 1x Electrically Isolated EZO™ Carrier Board
• 2x 125ml (4oz) calibration solutions
• K 1.0 – This set includes 1 (12,880µS) and 1 (80,000µS

Features:

Electrical Conductivity Circuit

• Specific gravity of sea water
• Accuracy +/- 2%
• Full E.C. range from 0.07 μs/cm to 500,000+ μs/cm
• Temperature dependent or temperature
• independent readings
• Flexible calibration protocol supports single point
• or dual point calibration
• Calibrate to any E.C. value
• Calibration required only once per year
• Data format is ASCII

Two data protocols

• UART asynchronous serial connectivity
• (RX/TX voltage swing 0-VCC)
• I2C (default I2C address 0x64)
• Operating voltage: 3.3V to 5V
• Works with any off-the-shelf two conductor conductivity probe
• Works with any K value from K 0.1 to K 10

Sleep mode power consumption

• 0.4mA at 3.3V

Conductivity K 1.0 Probe

• Body material: Epoxy
• Max Temperature: 0-70°C
• Max PSI: 1379 kPa (200PSI)
• Cable length: 1 Meter
• Carrier Board dimensions: 56.2mm x 32mm (2.2″ x 1.2″)

Typical Applications

• Standard Lab use
• Field use
• Aquarium
• Hydroponics
• Food Safe
• Fish keeping
• Mixed aqueous/organic
• Samples containing Heavy metals
• Soil Samples
• Strong reducing agents

Documents:

• EZO™ Conductivity Circuit Datasheet
• Conductivity Probe K 1.0 Datasheet
• EZO™ Conductivity Accuracy Graph
• Electrically Isolated EZO™ Carrier Board Datasheet
• Wiring Diagram
• Arduino Uno Sample Code
• Arduino Mega Sample Code
• Arduino I2C Sample Code
• Raspberry Pi Sample Code (UART, I2C, USB)
• Connecting probes into a pipe
• How to properly cut your probe cable
• Conductivity CAD Footprint File (*.dxf)
• Dual Probe Holder - 3D printer file
• Product Page
