RB35 - Motor 12V DC 1:30

:MOT02065
28,50 €
preço com IVA incluído

Motor de 12V 174rpm bastante resistente, silencioso, pequeno e de elevada eficiência para aplicar nos seus projectos.

Quantidade

DESCRIÇÃO EM PORTUGUÊS BREVEMENTE DISPONÍVEL

Se tiver alguma dúvida neste produto não hesite em contactar-nos.

*Atenção: as imagens são meramente ilustrativas.

Description

Excellently machined, high resistance, quiet, small yet still offering high efficiency. The input and output shafts are offset slightly.

Features



  • Engine idle speed 6000 min floater
  • Engine idle speed 4650 min floater
  • Engine torque 35 g / cm
  • Engine-idle power consumption apprx. 80 mA (without transmission)
  • Engine power consumption under load apprx. 300 mA
  • Engine-Ø 35 mm
  • Gear-Ø 37 mm
  • Efficiency 66%

Datasheet

Technical data

Gear reduction 1:30
Category Transmission Motors
Operating voltage 12 V
Shaft Ø 6 mm
Peak torque 60 Ncm
Max. transmission load 6 kg/cm · permanent 2 kg/cm
Nominal voltage 12 V
Idle speed (nominal) 200 rpm
Load speed 174 rpm
Max. load current 2.1 A
Gear reduction (details) 30:1
Shaft length 12 mm
Length 72 mm
(Ø) 37 mm
MOT02065
