Sensor Digital de Proximidade Infravermelho (1-400cm) - DFRobot SEN0531

:SEN03068
24,90 €
preço com IVA incluído

Este sensor de proximidade é capaz de detetar objetos que se apresentem entre 0cm e 400cm. Este produto conta também com um botão para ajustares a distancia que queres que o sensor leia e um indicador para te dar feedback se o sensor está a detetar ou não.

Se quiseres saber mais sobre este produto e ter acesso a códigos de exemplo, consulta a sua Wiki Page.

Quantidade

DESCRIÇÃO EM PORTUGUÊS BREVEMENTE DISPONÍVEL

Se tiver alguma dúvida neste produto não hesite em contactar-nos.

*Atenção: as imagens são meramente ilustrativas.

Introduction

This digital laser proximity sensor, the advanced version of Digital IR Proximity Sensor (SKU: SEN0381), offers a longer sensing distance and comes with an indicator for showing real-time sensor status. Keep pressing down the on-board button for 3 seconds, then the indicator starts to flash and the detection distance can be adjusted within 1 to 400cm as per your need. The sensor can automatically detect and save the distance between it and the obstacle ahead.

In addition, the sensor features digital signal output, which works well with the Arduino IO expansion board. It can be widely used in applications like smart homes, house security, intelligent detection and control, robot obstacle, and so on.

The sensor is based on the principle of diffuse reflection of laser on the object. When a person or object enters the sensing range in front of the sensor, the sensor immediately determines that there is induction, so as to control to output signal; after the person or object leaves the sensing range, it will judge that there is no induction, and stop signal output, by which intelligent control can be achieved.


Connection Diagram

Compatible with Arduino UNO R3 and IO Expansion Shield



Features

  1. Wide range of applications

  2. With on-board button for detection distance adjustment

  3. Laser sensing with the detection distance up to 4m



Applications

  1. Smart home

  2. House security

  3. Intelligent detection and control

  4. Robot obstacle



Specification

  1. Power Supply: DC 5-24V

  2. Load Current: 300mA

  3. Operating Current: 15mA

  4. Detection Distance: adjustable within 1-400cm

  5. Detection Accuracy: ±4%

  6. Wavelength: 940nm laser emitter

  7. Output Mode: high/low level

  8. Detection Angle: 35°(transmit), 25°(receive)

  9. Short Circuit Protection: disable output when over 1A

  10. Detection Mode: active mode

  11. Operating Ambient Temperature: -20-70°C

  12. Storage Temperature: -20°-85°C

  13. Waterproof Performance: IP67

  14. Material: filter: PC optical material, housing: PC-V0 fireproof material



Documents



Shipping List

  1. Digital Laser Proximity Sensor (1-400cm) x1



SEN03068
