Módulo MOSFET IRF5305 5~36Vdc 20A c/ entrada 3~24Vdc

DESCRIÇÃO EM PORTUGUÊS BREVEMENTE DISPONÍVEL

Se tiver alguma dúvida neste produto não hesite em contactar-nos.

*Atenção: as imagens são meramente ilustrativas.

Product description:

• FET module, the input and output are completely isolated.
• Signal trigger terminal: digital high and low level. Can be connected to the microcontroller IO port, PLC interface, DC power supply, etc.
• Input signal voltage: 3V~20Vdc; current: about 5mA.
• The output can control high-power equipment, motors, bulbs, LED strips, DC motors, micro pumps, solenoid valves, etc.
• Output controlled voltage: 5V~36Vdc. Current: less than 5A, more than 5A need to add heat sink, the maximum can not exceed 20A.
• Using the original F5305S power FET, you can input PWM, control motor speed, brightness of the lamp, etc.
