DESCRIÇÃO EM PORTUGUÊS BREVEMENTE DISPONÍVEL
Se tiver alguma dúvida neste produto não hesite em contactar-nos.
*Atenção: as imagens são meramente ilustrativas.
Manufacturer | SCI | |
Type of switch | door | |
Number of positions | 2 | |
Stable positions number | 1-position | |
Contacts configuration | SPST-NO | |
AC contacts rating @R (at resistance load) |
10A / 250VAC | |
Illumination | none | |
Backlight colour | none | |
Leads | 4,8mm connectors | |
Switching method (item in brackets is instantaneous) |
OFF-(ON) | |
Operating temperature | -20...85°C | |
Mounting hole diameter | Ø14.5mm | |
Mounting | on panel | |
Panel thickness | max 3mm | |
Body material | nylon | |
Contact plating | silver plated | |
Max. contact resistance: | 50mΩ |
