Grove - Sensor de Álcool
  • Grove - Sensor de Álcool

Grove - Sensor de Álcool

:SEN08019
9,90 €
preço com IVA incluído
Sensor de álcool com boa sensibilidade e resposta rápida ao álcool, adequado para detector de álcool portátil.
Quantidade
Sem Stock


DESCRIÇÃO EM PORTUGUÊS BREVEMENTE DISPONÍVEL

Se tiver alguma dúvida neste produto não hesite em contactar-nos.

*Atenção: as imagens são meramente ilustrativas.

DESCRIPTION:


Alcohol sensor is semiconductor sensor for alcohol detection. It has good sensitivity and fast response to alcohol, suitable for portable alcohol detector.

Specifications
  • Power requirements: 5 VDC @ ~120 mA (heater on)
  • Detection Gas: Alcohol
  • Concentration: 20-1000ppm Alcohol
  • Interface: 1 TTL compatible input (SEL), 1 TTL compatible output (DAT)
  • Dimension: 40×20×12mm
  • Heater Voltage: 0.9V ± 0.1V AC or DC
  • Heater Current: 120±20mA

Application Ideas:
  • Alcohol level over-limit alarm
  • Stand-alone/background sensing device
  • Environmental monitoring equipment

Documents:

Please visit our wiki page for more info about this product. It will be appreciated if  you can help us improve the documents, add more demo code or tutorials. For technical support, please post your questions to our forum.

More information about gas sensor, please refer to this manual.

SEN08019
