T-Call TTGO ESP32 w/ SIM800L 16MB GSM/GPRS and driver CH9102 - LILYGO® Q103-01

: PCO05099
€32.50
Tax included

A powerfull ESP32 with SIM800L GSM comunication module!



Quantity

If you have any questions on this product please feel free to contact us.

*Disclaimer: The images are merely illustrative.

More info and updated documentation on LilyGo product page (T-SIM800L 16MB [Q103-01])

The LILYGO® T-Call V1.4 is an exceptional development board designed for IoT enthusiasts and professionals alike. It features a powerful ESP32 MCU, GSM/GPRS SIM800L, and Nano Card Slot, offering a high-performance wireless connection that supports 2G networks.

With Wi-Fi 802.11 b/g/n and Bluetooth v4.2 BR/EDR and BLE wireless connectivity, the T-Call V1.4 is perfect for a wide range of IoT projects. The board also features a clock speed of 240Mhz, 4MB Flash, and 8MB PSRAM for efficient data processing and storage.

The T-Call V1.4 also supports various peripheral interfaces, including I2C, SPI, UART, SDIO, I2S, and CAN. It comes with a JST Connect type: JST PH 2pin 2.0mm power supply that supports USB Type-C / Li-Po Battery Dual Power Supply.

This development board is designed with user convenience in mind. It supports pin extension of Mic and Speaker, making it easy to integrate audio functionality into your IoT projects. It comes with a power cable (PH 2pin 2.0mm), SIM antenna (~7 cm), and two pins, making it easy to set up and start working on your project.

If you need technical support, you can find more information on the LILYGO® GitHub page. The T-Call SIM800 is an excellent device that offers exceptional performance and support. Don't wait any longer to get your hands on the LILYGO® T-Call V1.4 development board and take your IoT projects to the next level!

Properties

Brand information

Brand LilyGo
Model Q103-01
More info GitHub - Xinyuan-LilyGO/LilyGo-T-Call-SIM800

Functionality

Position Micro controller
Communication Wi Fi
Communication GPRS
Communication bluetooth

Connection data

Voltage 3,3 V - 5 V
Connection SIM card
Connection USB-C
Spanning I/O 3,3 V

Datasheet

Flash memory 4 MB
Microcontroller ESP32
Clock speed 240 MHzdual-core
SRAM 520 KB
Chip SIM800LGSM GPRS modules
PSRAM 8 MB
USB to-serial converter CP2104 or CH9102F

To belong

USB Cable included no

Battery

Battery type Li-ion
Battery type LiPo
Battery included no
Charging circuit IP5306
Protect circuit Yes
Battery voltage 3,7V
Battery connection 2pin JST-PH

Size info

Length 29 mm
Width 75 mm
Height 5 mm
T-Call-SIM800H_1024x1024.jpg?v=1702371049

SIM800H

1 X SIM800L

1 X Power Cable(PH 2pin 2.0mm)

1 X SIM Antenna(~7 cm)

2 X Pin

1x GSM(GPRS Antenna

GSMGPRS_-Antenna-lilygo_1_1024x1024.jpg?v=1661843911
