li-ion 18650 BMS Charger PCB Prot. Board, 4S 14.4V~16.8V 6A
: BAT04011
€3.98
If you have any questions on this product please feel free to contact us.
*Disclaimer: The images are merely illustrative.
Description:
- 4 series 18650 battery 16.8V 16V 14.8V
- 14.8V (Li-ion 18650 or li-ion battery rated voltage)
- 16.8V (Li-ion battery full charge voltage)
- 14.4V ( Lipo battery pack rated voltage)
- The lithium battery protection board is not included the welding tabs
- Over Charge Voltage:4.25-4.35v±0.05v
- Over Discharge Voltage: 2.3-3.0v±0.05v
- Max working current:4-5A
- Max Peak current:6-7A
- Working Temperature:-40---+50
- Storage Temperature:-40-- +80
- Small current:6uA
- Life cycle:50000hours
- Resistance:45m
- Short cut Protection:Protectable
- Size:67*16*1.0mm
- High-accuracy voltage detection circuit;
- Terminal of the charger using high voltage device;
- Built-in three-stage over-current detection circuit (over-current 1, over-current 2, or load short circuit);
- CMOS transistor can control the battery charge and discharge;
- Low standby current consumption.
