Conversor PoUSB USB para RS232
  • Conversor PoUSB USB para RS232
  • Conversor PoUSB USB para RS232
  • Conversor PoUSB USB para RS232

PoUSB12

: CNV01001
€14.08

Super compact USB-Serial converter PoUSB12 (UART bridge)

Quantity

Super compact USB-Serial converter PoUSB12 (UART bridge).



Specifications:



  • USB 2.0 compliant (12Mbps maximum speed)
  • Suspend supported
  • Xon/Xoff handshaking supported (300bps to 1Mbps)
  • UART supports 5-8 bit data, 1-2 Stop bits, odd/even and no parity
  • Integrated EEPROM for Vendor ID, product ID, serial and release number
  • On-chip 3.3V regulator available with power on reset circuit
  • USB powered
  • TX and RX signal levels are between 0V and 3.3V (5V tolerant)
  • Temperature range: -40ºC to +85°C
  • Small size: 17 x 12 x 15 (mm)
  • Virtual COM port drivers for Windows, Linux and MACOS
  • Can be used as ICP programmer for LPC2000 microcontrolers



Downloads:

Datasheet

Drivers



* Note: Product may not be exactly as shown in image. Contact us for more information.

CNV01001
