Digital multimeter 10A 1000V 2M? K Type Temperature - REBEL RB-838 v.2

: FER02067
€4.90
Tax included

Compact digital multimeter with manual range selection for AC/DC voltage, DC current, resistance and temperature measurements. Features diode, transistor hFE and continuity testing, low-battery indication and automatic polarity detection.

Quantity

If you have any questions on this product please feel free to contact us.

*Disclaimer: The images are merely illustrative.



The REBEL RB838 v.2 is a compact digital multimeter designed for electrical and electronics measurements. It measures DC voltage up to 1000 V, AC voltage up to 750 V, DC current up to 10 A and resistance up to 2 MΩ.

The multimeter features manual range selection, low-battery indication and automatic polarity detection. It also provides diode, transistor hFE, continuity and temperature testing using a K-type thermocouple. The display provides a maximum reading of 1999 with a sampling rate of 2 readings per second.



Technical Specifications

Brand REBEL
Model RB838 v.2
Part Number MIE-RB-838.2
EAN 5901890116565
DC Voltage 200 mV / 2 V / 20 V / 200 V / 1000 V
DC Accuracy ±(1% + 5)
AC Voltage 200 V / 750 V
AC Accuracy ±(2% + 10)
DC Current 2000 µA / 20 mA / 200 mA / 10 A
DC Accuracy ±(2% + 10)
Resistance 200 Ω / 2 kΩ / 20 kΩ / 200 kΩ / 2 MΩ
Resistance Accuracy ±(1% + 4)
Diode Test Yes
Transistor Test hFE
Continuity Test Yes
Temperature Measurement Yes
Range Selection Manual
Polarity Automatic
Low Battery Indicator Yes
Maximum Display 1999
Display Size 45 × 13 mm
Sampling Rate 2 times/s
Operating Temperature 0 °C to 40 °C
Operating Humidity <80%
Storage Temperature -10 °C to 50 °C
Storage Humidity <85%
Power Supply 1 × 9 V battery
Dimensions 122 × 66 × 24 mm
Weight 107 g



Package Contents

  • 1 × REBEL RB838 v.2 multimeter
  • 1 × Test lead set
  • 1 × K-type thermocouple
  • 1 × User manual
