Makeblock - Solenoid Valve (5/2way)
The 5/2way solenoid valve is usually used with a double-acting pneumatic actuator. It controls positive or negative direction of movement via powering on/off.
The 5/2 way solenoid valve comes with M5 threaded straight hole and works well with φ4 pneumatic air tube.
If you have any questions on this product please feel free to contact us.
*Disclaimer: The images are merely illustrative.
Description:
The 5/2way solenoid valve is usually used with a double-acting pneumatic actuator. It controls positive or negative direction of movement via powering on/off.
The 5/2 way solenoid valve comes with M5 threaded straight hole and works well with φ4 pneumatic air tube.
Features:
- Suitable for M5 screw & φ4 air tube;
- Press range varying from 0.15 to 0.8 Mpa;
- Flow Cv=0.31;
- Working temperature: -20 to 70℃;
- Maximum movement frequency: 5 times per second.
Size Chart (mm):
- Product Dimension Height/Width/Length: 90 x 26 x 18 mm (3.54 x 1.02 x 0.71 inch)
- Package Dimension Height/Width/Length: 110 x 150 x 18 mm (4.33 x 5.91 x 0.71 inch)
Part List:
1 x Solenoid Valve (3/2way) 3V110M5NCFI
1 x General Copper Silencer
1 x φ4 Straight Connector
