• DISCONTINUED

LM2596 HV Step Down 15W

:FAL08017
€3.17
Tax included

This is an LM2596 DC-DC buck converter step-down power module with high-precision potentiometer. Output voltage: 3 to 35 v

If you have any questions on this product please feel free to contact us.

*Disclaimer: The images are merely illustrative.

Specification

  • Input voltage: 4.5 to 60 v
  • Output voltage: adjustable 3-35 v (default delivery voltage 5 v)
  • Output current: rated current 2 A, maximum 3 A, 12 v turn 5 v)
  • Output power: maximum 15 W
  • Conversion efficiency: up to 92%
  • Static power consumption is only about 6 mA.
  • Working temperature: industrial grade (- 40 to + 85 ℃)
  • Input mode: IN+ (input positive), IN - (input negative)
  • Output mode: OUT+ (output positive), OUT- (output negative)
  • Size: 45 * 22 * 13.5 mm (included potentiometer)
  • Load regulation: ±1%
  • Voltage regulation: ±0.5% (in order to reach the point at which the no-load output voltage will be higher, but as long as there is with 1 mA load, the output voltage is normal, and will not affect the function, please be assured about that when use it.)
  • Short circuit protection: current limiting, overheating protection, but since the recovery.

Additional Information

Weight 14 g
Max Output Current 3A
FAL08017
